ENDRUST® UB702 – Premium High-Build Anti-Corrosive Epoxy

Heavy-Duty Protection for the Harshest Environments

ENDRUST® UB702 is a premium two-pack, high-build epoxy coating developed for long-term corrosion protection in demanding automotive, mining, industrial and marine environments.

Forming an extremely hard, tough protective film, UB702 provides outstanding resistance to abrasion, moisture, salt, chemicals and solvents. Its high-build formulation delivers excellent coverage over edges, welds and exposed steelwork, helping protect the areas most vulnerable to corrosion.

UB702 is Endrust’s toughest underbody coating, making it particularly suitable for new 4WDs, commercial vehicles, mining fleets, heavy machinery and equipment operating in aggressive environments.

Features & Benefits

✔ Exceptional Abrasion Resistance — Built for Tough Conditions

The cured two-pack epoxy forms a hard, durable protective barrier that withstands the wear and abrasion associated with demanding vehicle and equipment applications.

✔ High-Build Protection — Up to 200 Microns Per Coat

With approximately 80% volume solids, UB702 achieves a dry film thickness of 175–200 microns per coat, providing substantial protection in a single application.

✔ Excellent Corrosion and Chemical Resistance

Provides very good resistance to moisture, salt, alkalis, chemicals and solvents, making it particularly suitable for mining, coastal, marine and industrial environments.

✔ Superior Edge and Weld Protection

The high-build formulation provides excellent film coverage over sharp edges, welds, corners and other areas where corrosion commonly begins.

✔ Ideal for New Vehicles and Prepared Steel

UB702 performs particularly well on clean, sound factory-painted surfaces that have been properly prepared. It is also suitable for prepared bare steel and sound existing hard coatings.

✔ Versatile Industrial Applications

Suitable for vehicle underbodies, chassis exteriors, heavy machinery, marine equipment, structural steelwork and other assets requiring durable corrosion protection.

Recommended Applications

ENDRUST® UB702 is recommended for:

• 4WDs, commercial vehicles and mining fleets – external underbody, chassis and running gear protection.
• Mining and industrial machinery – heavy equipment, drilling rigs and exploration equipment.
• Marine and coastal equipment – exposed steelwork and equipment operating in salt-laden environments.
• Industrial facilities – structural steel, pipes, tank exteriors and general steelwork.
• Construction and agricultural equipment – durable protection against corrosion and abrasive operating conditions.

UB702 is the primary external underbody coating used in Endrust’s Premium Epoxy Mine Specifications 7, 8 and 9, and can also be selected as a premium upgrade for other suitable applications.

Technical Information

Property	Specification
Product Type	Two-pack, high-build epoxy
Colours	Black or Light Grey
Finish	Semi-gloss
Mix Ratio	4 parts Base : 1 part Hardener (by volume)
Volume Solids	Approximately 80%
Dry Film Thickness	175–200 microns per coat
Theoretical Coverage	Approximately 4 m²/L at 200 microns DFT
Application	Airless spray preferred; conventional spray or brush for small areas
Pot Life	Approximately 5 hours at 25°C
Full Cure	7 days
Temperature Resistance	Up to 93°C dry heat
Packaging	4L and 10L kits

Surface Preparation & Application

For best results, surfaces must be clean, dry and free from oil, grease, loose rust and contamination.

On vehicles, UB702 performs best on sound factory-painted surfaces that have been cleaned and lightly abraded to provide a suitable key. Rusted or bare steel surfaces require appropriate preparation before coating.

UB702 is designed for external underbody, running gear and chassis surfaces. It should not be applied over bituminous, wax-based or other soft coatings. For Endrust vehicle treatment systems, internal chassis rails are treated separately with ENDRUST® UB302B.

UB702 may be used as a standalone protective coating or topcoated where required. When exposed to exterior weathering without a topcoat, some surface chalking may occur without affecting the coating’s protective performance.

Important: UB702 is a professional two-pack coating. Always refer to the current Technical Data Sheet and Safety Data Sheets for mixing, preparation, application, curing and safety requirements.

Available Colours & Sizes

• UB702B – Black: 4L and 10L kits
• UB702G – Light Grey: 4L and 10L kits

For product selection, technical advice or larger commercial and fleet requirements, contact Endrust Australia or your nearest Endrust Certified Applicator.
